| Engine Description | Air-cooled, Evolution
|
| Fuel System | Electronic Sequential Port Fuel Injection (ESPFI)
|
| Cooling | Air Cooling
|
| Displacement | 883 cc
|
| Maximum Torque | 70 Nm @ 3500 rpm
|
| Number of Cylinders | 2
|
| Compression Ratio | 9:01
|
| Bore | 76.2 mm
|
| Stroke | 96.8 mm
|
| Engine Torque Testing Method | EEC/95/1
|
| Primary drive | Chain, 34/57 ratio
|
| Number of Gears | 5 |
| Gear Ratios | 1st-9.315, 2nd-6.653, 3rd-4.948, 4th-4.102, 5th-3.517
|
BRAKES & TYRES
| |
| Front Brake | 292mm Disc, 2-piston caliper
|
| Rear Brake | 292mm Disc, 2-piston caliper
|
| ABS | Optional
|
| Front Tyre | 100/90B19 57H
|
| Rear Tyre | 150/80B16 77H
|
| Front Wheel | Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
|
| Rear Wheel | Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
|
| Rear Wheel | Black, Split 9-Spoke Cast Aluminum w/ Machined Highlights
|
| Wheel Type | Black, 13-Spoke Cast Aluminum
|
SUSPENSION & CHASSIS
| |
| Front Suspension | 39 mm telescopic forks
|
| Rear Suspension | Coil-Over; Preload dual-adjustable
|
| Frame | Mild steel-tubular frame, Circular section, cast junctions
|
| Exhaust/Muffler | Chrome, staggered shorty exhaust with dual mufflers
|
DIMENSIONS & WEIGHT
| |
| Overall Length | 2185 mm
|
| Overall Width | 820 mm
|
| Overall Height | 1120 mm
|
| Ground Clearance | 140 mm
|
| Seat Height | 760 mm
|
| Wheelbase | 1515 mm
|
| Dry Weight | 247 kg
|
| Kerb/Wet Weight | 256 kg
|
| Fuel Tank Capacity | 12.50 litres
|
| Engine Oil Capacity | 2.6 litres
|
INSTRUMENT CONSOLE FEATURES
| |
| Speedometer | Handlebar-mounted electronic speedometer
|
| Trip Meter | Digital
|
| Fuel Gauge | Digital
|
BATTERY & LIGHTING
| |
| Battery Type | Maintenance Free
|
