| Engine Description | Liquid-cooled 4-stroke DOHC single cylinder
|
| Fuel System | Fuel Injection
|
| Cooling | Liquid Cooling
|
| Displacement | 286 cc
|
| Maximum Power | 30.4 HP @ 8500 rpm
|
| Maximum Torque | 27.1 Nm @ 7250 rpm
|
| Number of Cylinders | 1 |
| Compression Ratio | 10.7:1
|
| Bore | 76 mm
|
| Stroke | 63 mm
|
| Valve System | 4 Valves per cylinder
|
| Spark Plug Model Type | SIMR8A9
|
| Throttle Bore | 38 mm
|
| Number of Gears | 6
|
| Clutch | Wet, Multiplate Disc
|
| Gear Ratios | 1 - 3.416 2 - 2.250 3 - 1.650 4 - 1.350 5 - 1.166 6 - 1.038
|
| Final Drive | Chain |
BRAKES & TYRES
| |
| Front Brake | 296mm Hydraulic Disc
|
| Rear Brake | 220mm Hydraulic Disc
|
| ABS | No |
| Swing Arm Length | 573.6 mm
|
| Front Tyre | 110/70-17
|
| Rear Tyre | 140/70-17
|
| Front Wheel | 17M/C×MT2.75, Cast aluminium
|
| Rear Wheel | 17M/C×MT4.00, Cast aluminium
|
| Wheel Type | Alloys |
| Tyres Type | Tubeless |
SUSPENSION & CHASSIS
| |
| Front Suspension | 37mm conventional fork
|
| Rear Suspension | Mono-shock, Pro-link
|
| Frame | Diamond Steel
|
| Exhaust/Muffler | Single |
DIMENSIONS & WEIGHT
| |
| Overall Length | 2030 mm
|
| Overall Width | 709.5 mm
|
| Overall Height | 1127 mm
|
| Ground Clearance | 145 mm
|
| Seat Height | 785 mm
|
| Wheelbase | 1380 mm
|
| Kerb/Wet Weight | 164 kg
|
| Fuel Tank Capacity | 13 litres
|
| Engine Oil Capacity | 1.8 litres
|
INSTRUMENT CONSOLE FEATURES
| |
| Speedometer | Digital |
| Tachometer | Analog |
| Trip Meter | Digital |
| Odometer | Digital |
BATTERY & LIGHTING
| |
| Battery Type | 12V 6Ah MF |
| Head Light | 12V; 55W x 2 (high) / 55W x 1 (low)
|
| Tail Light | Tail;12V 5W / Stop Light ;12V 21W
|
COMFORT & CONVENIENCE FEATURES
| |
Electric Start
| Yes |
| Split Seat | Yes |
Pillion Footrest
| Yes |
