| Engine Description | Liquid-Cooled, parallel twin
|
| Fuel System | PGM FI
|
| Cooling | Liquid Cooling
|
| Displacement | 471 cc
|
| Maximum Power | 46.9 Bhp @ 8500 rpm
|
| Maximum Torque | 43 Nm @ 7000 rpm
|
| Number of Cylinders | 2 |
| Compression Ratio | 10.7 : 1
|
| Bore | 67 mm
|
| Stroke | 66.8 mm
|
| Valve System | 4 valves per cylinder
|
| Number of Gears | 6 |
| Clutch | Multi plate wet
|
| Final Drive | Chain |
BRAKES & TYRES
| |
| Front Brake | Single Wavy Disk, 320mm, 2 POT caliper
|
| Rear Brake | Single Wavy Disk, 240mm, 1 POT caliper
|
| Front Tyre | 120/70ZR - 17M/C (On-Off Pattern)
|
| Rear Tyre | 160/60ZR - 17M/C (On-Off Pattern)
|
| Wheel Type | Alloys |
| Tyres Type | Tubeless |
SUSPENSION & CHASSIS
| |
| Front Suspension | Conventional Telescopic, 41mm
|
| Rear Suspension | Prolink mono with 9 stage Preload adjuster, steel square pipe swingarm
|
| Frame | Steel, Diamond
|
| Exhaust/Muffler | 2-1 manifold with Catalyst and 02 feedback
|
DIMENSIONS & WEIGHT
| |
| Overall Length | 2096 mm
|
| Overall Width | 822 mm
|
| Overall Height | 1262 mm
|
| Seat Height | 810 mm
|
| Ground Clearance | 165 mm
|
| Wheelbase | 1421 mm
|
| Kerb/Wet Weight | 195 kg
|
| Fuel Tank Capacity | 17.3 litres
|
| Engine Oil Capacity | 3.2 litres
|
INSTRUMENT CONSOLE FEATURES
| |
| Speedometer | Digital |
| Tachometer | Digital Bar Graph
|
| Trip Meter | Analog-2
|
BATTERY & LIGHTING
| |
| Battery Type | 12V 8.6Ah MF |
| Head Light | Irregular Shape, 60/55W x 1 light
|
| Tail Light | 1 Light (Bulb)
|
COMFORT & CONVENIENCE FEATURES
| |
Electric Start
| Yes |
| Split Seat | Yes |
| Security System | HISS (Honda Intelligent Security System)
|
