| Engine Description | 199.6cc, Oil-Cooled, 4-Stroke, 2-Valve, Single Cylinder, OHC
|
| Fuel System | Advanced Programmed Fuel Injection
|
| Cooling | Oil Cooled
|
| Displacement | 199.6 cc
|
| Maximum Power | 17.8 HP @ 8500 rpm
|
| Maximum Torque | 16.45 Nm @ 6500 rpm
|
| Number of Cylinders | 1 |
| Emission Standard | BS6-Compliant
|
| Ignition | Digital DC CDI Ignition System
|
| Compression Ratio | 10.0:1
|
| Bore | 66.5 mm
|
| Stroke | 57.5 mm
|
| Air Filter Type | Viscous Type
|
| Number of Gears | 5 |
| Gearbox Type | Constant Mesh
|
| Clutch | Multi Plate Wet Clutch
|
BRAKES & TYRES
| |
| Front Brake | 276mm Single Disc
|
| Rear Brake | 220mm Single Disc
|
| ABS | 1-Channel ABS |
| Front Tyre | 100/80-17
|
| Rear Tyre | 130/70 -R17 Radial
|
| Wheel Type | Alloys |
| Tyres Type | Tubeless |
SUSPENSION & CHASSIS
| |
| Front Suspension | Telescopic (37 mm Dia), Anti Friction Bush
|
| Rear Suspension | 7 Step Rider-Adjustable Monoshock
|
| Frame | Diamond |
DIMENSIONS & WEIGHT
| |
| Overall Length | 2120 mm
|
| Overall Width | 807 mm
|
| Overall Height | 1090 mm
|
| Ground Clearance | 177 mm
|
| Seat Height | 799 mm
|
| Wheelbase | 1392 mm
|
| Kerb/Wet Weight | 150 kg
|
| Fuel Tank Capacity | 13 litres
|
INSTRUMENT CONSOLE FEATURES
| |
| Speedometer | Digital |
| Tachometer | Digital |
| Trip Meter | Digital |
| Odometer | Digital |
BATTERY & LIGHTING
| |
Pass Light
| Yes |
| Battery Type | 12V 4Ah MF |
| Head Light | LED (AHO) |
| Tail Light | LED |
COMFORT & CONVENIENCE FEATURES
| |
Pillion Grabrail
| Yes |
Electric Start
| Yes |
