| Engine Description | 400cc, 2-Cylinder Inline, 4-Stroke, Liquid-Cooled, DOHC
|
| Fuel System | EFI |
| Cooling | Liquid Cooled
|
| Displacement | 400 cc
|
| Maximum Power | 41 HP @ 9500 rpm
|
| Maximum Torque | 32 Nm @ 7750 rpm
|
| Number of Cylinders | 2 |
| Emission Standard | BS6-Compliant
|
| Ignition | ECU |
| Compression Ratio | 11.1:1
|
| Bore | 68.4 mm
|
| Stroke | 54.5 mm
|
| Number of Gears | 6 |
| Gearbox Type | 6-Speed
|
| Clutch | Wet Multi-Plate
|
BRAKES & TYRES
| |
| Front Brake | Double Disc, J.JUAN Double-Piston Caliper
|
| Rear Brake | Single Disc, J.JUAN Single-Piston Caliper
|
| ABS | Continental AG, Dual Channel
|
| Front Tyre | 120/70-ZR17 M/C
|
| Rear Tyre | 160/60-ZR17 M/C
|
| Wheels Type | Alloy |
SUSPENSION & CHASSIS
| |
| Front Suspension | Telescopic Forks
|
| Rear Suspension | Mono Suspension, Side Aligned (Adjustable Preload and Rebound)
|
| Frame | Diamond High Tensile Steel Frame
|
DIMENSIONS & WEIGHT
| |
| Overall Length | 2114 mm
|
| Overall Width | 830 mm
|
| Overall Height | 1105 mm
|
| Ground Clearance | 150 mm
|
| Seat Height | 780 mm
|
| Wheelbase | 1415 mm
|
| Kerb/Wet Weight | 206 kg
|
| Fuel Tank Capacity | 17 litres
|
INSTRUMENT CONSOLE FEATURES
| |
| Speedometer | Digital |
| Tachometer | Digital |
| Trip Meter | Digital |
| Odometer | Digital |
BATTERY & LIGHTING
| |
| Battery Type | MF |
| Head Light | LED |
| Tail Light | LED |
COMFORT & CONVENIENCE FEATURES
| |
| Engine Kill Switch | Yes |
| Electric Start | Yes |
| Split Seat | Yes |
Riding Modes
| Yes |
