| Engine Description | 249.2cc, Single-Cylinder, Liquid-Cooled
|
| Fuel System | Electronic Fuel Injection
|
| Cooling | Liquid Cooled
|
| Displacement | 249.2 cc
|
| Maximum Power | 27.5 HP @ 9750 rpm
|
| Maximum Torque | 22 Nm @ 7500 rpm
|
| Number of Cylinders | 1 |
| Emission Standard | BS6-Compliant
|
| Ignition | ECU |
| Compression Ratio | 11.3:1
|
| Bore | 72 mm
|
| Stroke | 61.2 mm
|
| Valve System | DOHC, 4 Valves
|
| Number of Gears | 6 |
| Clutch | Slipper Clutch, Wet Multi Plate
|
BRAKES & TYRES
| |
| Front Brake | 292mm Single Disc, Opposite Four-Piston Caliper
|
| Rear Brake | 220mm Single Disc, Single-Piston Floating Caliper
|
| ABS | Continental AG, 2-Channel ABS
|
| Front Tyre | 110/70-R17
|
| Rear Tyre | 140/60-R17
|
| Tyres Type | Tubeless |
| Wheels Type | Alloy |
SUSPENSION & CHASSIS
| |
| Front Suspension | 37mm Telescopic Upside Down Forks
|
| Rear Suspension | Mono Suspension, Centre Aligned
|
DIMENSIONS & WEIGHT
| |
| Overall Length | 2010 mm
|
| Overall Width | 750 mm
|
| Overall Height | 1080 mm
|
| Ground Clearance | 135 mm
|
| Seat Height | 780 mm
|
| Wheelbase | 1360 mm
|
| Kerb/Wet Weight | 165 kg
|
| Fuel Tank Capacity | 12 litres
|
INSTRUMENT CONSOLE FEATURES
| |
| Speedometer | Digital |
| Tachometer | Digital |
| Trip Meter | Digital |
| Odometer | Digital |
BATTERY & LIGHTING
| |
| Battery Type | Maintenance Free
|
| Head Light | LED |
| Tail Light | LED |
Automatic Headlamp On (AHO)
| Yes |
COMFORT & CONVENIENCE FEATURES
| |
Electric Start
| Yes |
Engine Kill Switch
| Yes |
| Split Seat | Yes |
