| Engine Description | 300cc, 2 Cylinder, Liquid Cooling
|
| Fuel System | EFI |
| Cooling | Liquid Cooling
|
| Displacement | 300 cc
|
| Maximum Power | 38.26 HP @ 11500 rpm
|
| Maximum Torque | 26.5 NM @ 10000 rpm
|
| Number of Cylinders | 2 |
| Emission Standard | BS4
|
| Ignition | Digital |
| Compression Ratio | 12:1
|
| Bore | 65 mm
|
| Stroke | 42.5 mm
|
| Number of Gears | 6-Speed
|
| Clutch | Wet Multi-Plate
|
| Final Drive | Chain Drive
|
BRAKES & TYRES
| |
| Front Brake | 260mm Petal Discs
|
| Rear Brake | 240mm Petal Disc
|
| ABS | Dual Channel |
| Front Tyre | 120/70 - 17
|
| Rear Tyre | 160/60 - 17
|
| Alloy Wheels | Yes (Aluminum)
|
SUSPENSION & CHASSIS
| |
| Front Suspension | Inverted Telescopic Forks
|
| Rear Suspension | Off-Set Rear Monoshock
|
| Frame | Steel Trestle
|
| Exhaust/Muffler | Two Catalytic Converter and Two Oxygen Sensor
|
DIMENSIONS & WEIGHT
| |
| Overall Length | 2130 mm
|
| Overall Width | 800 mm
|
| Overall Height | 1120 mm
|
| Seat Height | 795 mm
|
| Ground Clearance | 160 mm
|
| Wheelbase | 1410 mm
|
| Kerb/Wet Weight | 196 kg
|
| Fuel Tank Capacity | 16 litres
|
| Reserve Fuel Capacity | 3 litres
|
INSTRUMENT CONSOLE FEATURES
| |
| Speedometer | Digital |
| Tachometer | Analogue |
| Trip Meter | Digital |
| Odometer | Digital |
BATTERY & LIGHTING
| |
Pass Light
| Yes |
Automatic Headlamp On (AHO)
| Yes |
COMFORT & CONVENIENCE FEATURES
| |
Electric Start
| Yes |
Engine Kill Switch
| Yes |
Pillion Grabrail
| Yes |
