| Engine Description | Inline 2 cylinder DOHC, 4-Stroke
|
| Fuel System | Electronic Fuel Injection
|
| Cooling | Liquid-Cooled
|
| Displacement | 399.3 cc
|
| Maximum Power | 39.4 HP @ 9000 rpm
|
| Maximum Torque | 35 Nm @ 7000 rpm
|
| Number of Cylinders | 2 |
| Emission Standard | Euro 4
|
| Lubrication | Forced lubrication with wet sump
|
| Compression Ratio | 11.5:1
|
| Bore | 69 mm
|
| Stroke | 53.4 mm
|
| Valve System | DOHC
|
| Number of Gears | 6 |
| Clutch | Multidisc wet clutch
|
| Final Drive | Chain |
BRAKES & TYRES
| |
| Front Brake | Dual 260 mm disc brakes
|
| Rear Brake | Single 240 mm disc brake
|
ABS
| Dual Channel |
| Front Tyre | 120/70-ZR17
|
| Rear Tyre | 160/60-ZR17
|
| Wheel Type | Aluminium Alloy
|
| Tyres Type | Tubeless |
SUSPENSION & CHASSIS
| |
| Front Suspension | 41 mm USD Forks
|
| Rear Suspension | Shock absorber
|
| Frame | Trestle steel tubes and plates
|
| DIMENSIONS & WEIGHT | |
| Overall Length | 2276 mm
|
| Overall Width | 928 mm
|
| Overall Height | 1278 mm
|
| Seat Height | 740 mm
|
| Ground Clearance | 180 mm
|
| Wheelbase | 1600 mm
|
| Kerb/Wet Weight | 160 kg
|
| Fuel Tank Capacity | 16 litres
|
| Reserve Fuel Capacity | 3 litres
|
INSTRUMENT CONSOLE FEATURES
| |
| Speedometer | Digital
|
| Tachometer | Digital
|
| Trip Meter | Digital
|
| Odometer | Digital
|
BATTERY & LIGHTING
| |
Pass Light
| Yes |
| Battery Type | MF |
| Head Light | LED |
| Tail Light | LED |
COMFORT & CONVENIENCE FEATURES
| |
Electric Start
| Yes |
Engine Kill Switch
| Yes |
